GEOTHERMAL GROUT

Geothermal Grout is a specially blended high solids bentonite that can be mixed with sand, or graphite, in a two-part thermally conductive grouting material to improve the performance of ground source heat loop applications.  Geothermal Grout is an easy pumping grout that has been carefully developed to efficiently suspend solids (silica sand) for enhanced thermal conductivity. Thermal Conductivity range 0.4-1.90 Btu/hr/ft/F

GEOTHERMAL GRAPHITE

Geothermal Graphite is an additive used to boost the thermal conductivity of Geothermal Grout. The shape of our Geothermal graphite is a large flake which maximizes the thermal conductivity potential while reducing the amount of dust produced when utilizing the product in the field. Our Graphite is certified to NSF/ANSI Standard 60, Drinking Water Treatment Chemicals – Health Effects. Thermal Conductivity range  1.0-1.90 Btu/hr/ft/F

GEOTHERMAL U-BEND PIPE

• Ability to drill deeper than ever before
• Thicker, stronger pipe wall
• Smaller surface footprint
• Increased flow rate
• Improved geothermal efficiency
• Factory tested and certified

GEOTHERMAL Straight Pipe

Black geothermal straight pipe are made of high density polyethylene type PE4710

• Flexibility
• Long-term crack resistance
• Increased resistance to long-term fatigue cracking and high pressures
• Length of 20’, 40’ and 50’
• Diameter ½” to 10”
